15FL24 Series
Manufacturer: ULTRAVOLT / Advanced Energy
Beta
⌘K
DC/DC CONVERTER
| Part | Voltage - Output 3 | Package / Case | Voltage - Input (Max) [Max] | Approval Agency | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Mounting Type | Type | Power (Watts) | Voltage - Output 1 | Number of Outputs | Voltage - Isolation | Operating Temperature [Max] | Operating Temperature [Min] | Current - Output (Max) | Applications | Voltage - Input (Min) [Min] | Voltage - Output 2 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ULTRAVOLT / Advanced Energy | 5.6 V | 28-DIP Module | 26.4 V | CE cURus | 38.1 mm | 33 mm | 5.7 " | 1.5 " | 1.3 in | 144.8 mm | Through Hole | Isolated Module | 24 W | 24 V | 3 | 15000 VDC | 55 °C | -20 ░C | 1 A 10 mA | ITE (Commercial) | 21.6 V | -15 V |
ULTRAVOLT / Advanced Energy | ||||||||||||||||||||||
ULTRAVOLT / Advanced Energy | 5.6 V | 14-DIP Module | 26.4 V | CE cURus | 38.1 mm | 29.8 mm | 5.7 " | 1.5 " | 1.17 " | 144.8 mm | Through Hole | Isolated Module | 24 W | 24 V | 3 | 15000 VDC | 55 °C | -20 ░C | 1 A 10 mA | ITE (Commercial) | 21.6 V | -15 V |
ULTRAVOLT / Advanced Energy |
