395-084 Series
Manufacturer: EDAC Inc.
Beta
⌘K
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
| Part | Termination Rows [custom] | Material - Insulation | Contact Finish | Card Thickness [Max] | Card Thickness [Min] | Card Type | Read Out | Number of Positions [custom] | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Color | Termination | Number of Rows [custom] | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Mounting Type | Number of Positions/Bay/Row | Gender | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Black | Wire Wrap | 2 | -40 C | 105 ░C | Cantilever | Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | |
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Black | Solder Eyelet(s) | 2 | -40 C | 105 ░C | Cantilever | Board Edge Straddle Mount | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Board Edge Straddle Mount | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Flush Mount Threaded Insert Top Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Right Angle Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Right Angle Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | 4-40 Threaded Insert Top Mount Opening | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy | Card Guides | ||
 EDAC Inc. | 2 | Polyester Thermoplastic | Gold | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | Dual | 84 | 0.1 " | 2.54 mm | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Black | Solder | 2 | -40 C | 105 ░C | Cantilever | Right Angle Through Hole | 42 | Female | 0.25 Ám | 10 Áin | Copper Alloy |
