AFC0912 Series
Manufacturer: Delta Electronics
Beta
⌘K
DC FAN AXIAL BALL BEARING 12V 8V TO 13.2V 102.59CFM 53DB 92 X 92 X 25.4MM PWM/TACHOMETER
| Part | Material - Frame | Lifetime @ Temp. | Current Rating (Amps) | Material - Blade | Voltage Range [Min] | Voltage Range [Max] | Size / Dimension [y] | Size / Dimension [x] | Static Pressure | Static Pressure | Noise | Fan Type | Width [y] | Air Flow | Air Flow | Operating Temperature [Min] | Operating Temperature [Max] | Weight [custom] | Weight [custom] | Approval Agency | RPM | Power (Watts) | Termination | Features | Bearing Type | Voltage - Rated | Weight | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | Plastic | 70000 Hrs | 750 mA | Plastic | 8 V | 13.2 VDC | 92 mm | 92 mm | 131 Pa | 0.526 in H2O | 53 dB | Tubeaxial | 25.4 mm | 2.87 m³/min | 102.6 CFM | -10 °C | 60 °C | 0.265 lb | 120.2 g | CE CSA UL VDE | 4800 RPM | 9 W | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | Ball | 12 VDC | ||
 Delta Electronics | Plastic | 70000 Hrs | 0.31 A | Plastic | 7 V | 12.6 VDC | 92 mm | 92 mm | 38.8 Pa | 0.156 in H2O | 41.5 dB | Tubeaxial | 15 mm | 1.44 m³/min | 51.5 CFM | -10 °C | 60 °C | CE CSA UL VDE | 3300 RPM | 3.72 W | 4 Wire Leads | Locked Rotor Protection PWM Control Speed Sensor (Tach) | Ball | 12 VDC | 0.154 lb | 69.85 g |
