395-061 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 61POS 0.100
| Part | Material - Insulation | Termination Rows | Card Thickness [Max] | Card Thickness [Min] | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Gender | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Rows | Flange Feature [diameter] | Flange Feature [diameter] | Pitch | Pitch | Number of Positions/Bay/Row | Contact Finish | Color | Number of Positions | Termination | Read Out | Mounting Type | Contact Material | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Wire Wrap | Single | Through Hole | Copper Alloy | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Wire Wrap | Single | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.128 " | 3.25 mm | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Wire Wrap | Single | Through Hole | Copper Alloy | Side Mount Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.116 " | 2.95 mm | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Solder | Single | Through Hole | Copper Alloy | Floating Bobbin Top Mount Opening | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Wire Wrap | Single | Through Hole | Copper Alloy | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Solder | Single | Through Hole | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.156 " | 3.96 mm | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Solder | Single | Through Hole | Copper Alloy | Flush Mount Top Opening Unthreaded | |
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Solder | Single | Right Angle Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Solder | Single | Through Hole | Copper Alloy | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Cantilever | 0.25 Ám | 10 Áin | Female | Non Specified - Single Edge | -40 C | 105 ░C | 1 | 0.1 " | 2.54 mm | 61 | Gold | Black | 61 | Wire Wrap | Single | Through Hole | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | Card Guides |
