ECX-1048B Series
Manufacturer: ECS Inc.
Beta
⌘K
CRYSTALS CRYSTAL 32.000MHZ ECX-1048B +/-20PPM +/-20PPM 7PF 150 OHM FUNDAMENTAL -20C - 70C SURFACE MOUNT 4-SMD, NO LEAD W 1.20MM X 1.00MM) (0.33MM)
| Part | Frequency Tolerance | Frequency | Package / Case | ESR (Equivalent Series Resistance) | Mounting Type | Type | Operating Mode | Operating Temperature [Min] | Operating Temperature [Max] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Frequency Stability | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Load Capacitance | Height - Seated (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ECS Inc. | 20 ppm | 32 MHz | 4-SMD No Lead | 100 Ohms | Surface Mount | MHz Crystal | Fundamental | -20 ░C | 70 °C | 0.047 in | 1 mm | 0.039 in | 1.2 mm | 20 ppm | 0.35 mm | 0.014 " | 7 pF | |
 ECS Inc. | 10 ppm | 32 MHz | 4-SMD No Lead | 100 Ohms | Surface Mount | MHz Crystal | Fundamental | -30 ░C | 85 °C | 0.047 in | 1 mm | 0.039 in | 1.2 mm | 10 ppm | 0.35 mm | 0.013 " 0.014 " | 10 pF | 0.33 mm |
