PCE-C Series
Manufacturer: Adam Tech
Beta
⌘K
CONN SOCKET STRIP RCP 12 POS 2.54MM SOLDER ST THRU-HOLE
| Part | Insulation Material | Applications | Contact Material | Contact Shape | Material Flammability Rating | Insulation Color | Number of Positions | Termination | Contact Finish - Post | Fastening Type | Voltage Rating | Contact Type | Pitch - Mating | Pitch - Mating | Insulation Height | Insulation Height | Style | Contact Length - Post [x] | Contact Length - Post [x] | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Mounting Type | Number of Rows | Number of Positions Loaded | Features | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Adam Tech | Nylon 6/6 Polyamide (PA66) | Automotive General Purpose Medical Telecommunications | Phosphor Bronze | Square | UL94 V-0 | Natural | 12 | Solder | Tin | Push-Pull | 250 VAC | Non-Gendered | 0.1 " | 2.54 mm | 0.276 in | 7 mm | Board to Board Cable | 3.7 mm | 0.146 " | -40 C | 105 ░C | 3 A | Through Hole | 1 | All | Board Hooks | Receptacle Bottom Entry |
 Adam Tech | Nylon 6/6 Polyamide (PA66) | Automotive General Purpose Medical Telecommunications | Phosphor Bronze | Square | UL94 V-0 | Natural | 5 | Solder | Tin | Push-Pull | 250 VAC | Non-Gendered | 0.1 " | 2.54 mm | 0.276 in | 7 mm | Board to Board Cable | 3.7 mm | 0.146 " | -40 C | 105 ░C | 3 A | Through Hole | 1 | All | Board Hooks | Receptacle Bottom Entry |
 Adam Tech | Nylon 6/6 Polyamide (PA66) | Automotive General Purpose Medical Telecommunications | Phosphor Bronze | Square | UL94 V-0 | Natural | 8 | Solder | Tin | Push-Pull | 250 VAC | Non-Gendered | 0.1 " | 2.54 mm | 0.276 in | 7 mm | Board to Board Cable | 3.7 mm | 0.146 " | -40 C | 105 ░C | 3 A | Through Hole | 1 | All | Board Hooks | Receptacle Bottom Entry |
