2.5-V to 18-V hot swap controller
Key Features
• 2.5-V to 18-V OperationAccurate Current Limiting for StarupAccurate 25-mV Current Sense ThresholdTimed Overcurrent BreakerPower-Good OutputFast Breaker for Short-Circuit ProtectionLatch Off (TPS24700) and Retry Versions (TPS24701)Programmable UV ThresholdDrop-In Upgrade for LTC4211 – No Layout ChangesSmall MSOP-8 PackageAPPLICATIONSServer BackplanesStorage Area Networks (SAN)Medical SystemsPlug-In ModulesBase StationsConsumer Electronics2.5-V to 18-V OperationAccurate Current Limiting for StarupAccurate 25-mV Current Sense ThresholdTimed Overcurrent BreakerPower-Good OutputFast Breaker for Short-Circuit ProtectionLatch Off (TPS24700) and Retry Versions (TPS24701)Programmable UV ThresholdDrop-In Upgrade for LTC4211 – No Layout ChangesSmall MSOP-8 PackageAPPLICATIONSServer BackplanesStorage Area Networks (SAN)Medical SystemsPlug-In ModulesBase StationsConsumer Electronics
Description
AI
The TPS24700/1 is an easy-to-use, 2.5 V to 18 V, hot-swap controller that drives an external N-channel MOSFET. The programmable current limit and fault time protect the supply and load from excessive current at startup. After startup, currents above the user-selected limit are allowed to flow until programmed timeout – except in extreme overload events when load is immediately disconnected from source. The low, 25-mV current sense threshold is highly accurate and allows use of smaller, more-efficient sense resistors, yielding lower power loss and smaller footprint. A power-good output is provided for status monitoring and downstream load control.
TPS24700/1 replaces the LTC4211 in existing designs with no PCB board changes and only minor external component changes – yielding a more accurate, efficient solution.
The TPS24700/1 is an easy-to-use, 2.5 V to 18 V, hot-swap controller that drives an external N-channel MOSFET. The programmable current limit and fault time protect the supply and load from excessive current at startup. After startup, currents above the user-selected limit are allowed to flow until programmed timeout – except in extreme overload events when load is immediately disconnected from source. The low, 25-mV current sense threshold is highly accurate and allows use of smaller, more-efficient sense resistors, yielding lower power loss and smaller footprint. A power-good output is provided for status monitoring and downstream load control.
TPS24700/1 replaces the LTC4211 in existing designs with no PCB board changes and only minor external component changes – yielding a more accurate, efficient solution.
