833-83 Series

Manufacturer: Preci-Dip

Catalog

Catalog

CONN SOCKET 74POS 0.079 GOLD PCB

...

Part	Contact Shape	Contact Material	Number of Positions Loaded	Number of Rows [custom]	Contact Finish - Post	Row Spacing - Mating	Row Spacing - Mating	Material Flammability Rating	Connector Type	Contact Length - Post	Contact Length - Post	Mounting Type	Contact Type	Operating Temperature [Min]	Operating Temperature [Max]	Fastening Type	Number of Positions	Contact Finish Thickness - Mating [custom]	Contact Finish Thickness - Mating [custom]	Pitch - Mating	Pitch - Mating	Termination	Insulation Color	Insulation Height	Insulation Height	Current Rating (Amps)	Contact Finish - Mating	Contact Length - Post [x]	Contact Length - Post [x]
Preci-Dip 833-83-074-10-457101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket	0.118 in	3 mm	Through Hole	Female Socket	-55 C	125 °C	Push-Pull	74	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.409 in	10.4 mm	3 A	Gold
Preci-Dip 833-83-022-10-273101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket			Through Hole	Female Socket	-55 C	125 °C	Push-Pull	22	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black			3 A	Gold	0.122 in	3.1 mm
Preci-Dip 833-83-054-10-453101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket			Through Hole	Female Socket	-55 C	125 °C	Push-Pull	54	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.315 in	8 mm	3 A	Gold	0.126 "	3.2 mm
Preci-Dip 833-83-030-10-457101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket	0.118 in	3 mm	Through Hole	Female Socket	-55 C	125 °C	Push-Pull	30	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.409 in	10.4 mm	3 A	Gold
Preci-Dip 833-83-010-10-453101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket			Through Hole	Female Socket	-55 C	125 °C	Push-Pull	10	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.315 in	8 mm	3 A	Gold	0.126 "	3.2 mm
Preci-Dip 833-83-018-10-453101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket			Through Hole	Female Socket	-55 C	125 °C	Push-Pull	18	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.315 in	8 mm	3 A	Gold	0.126 "	3.2 mm
Preci-Dip 833-83-088-10-457101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket	0.118 in	3 mm	Through Hole	Female Socket	-55 C	125 °C	Push-Pull	88	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.409 in	10.4 mm	3 A	Gold
Preci-Dip 833-83-070-10-001101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket	0.125 in	3.18 mm	Through Hole	Female Socket	-55 C	125 °C	Push-Pull	70	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.165 in	4.2 mm	3 A	Gold
Preci-Dip 833-83-014-20-001101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket			Right Angle Through Hole	Female Socket	-55 C	125 °C	Push-Pull	14	29.5 µin	0.75 µm	0.079 "	2 mm	Solder	Black	0.165 in	4.2 mm	3 A	Gold	0.126 "	3.2 mm
Preci-Dip 833-83-040-64-001101	Circular	Beryllium Copper	All	2	Tin	2 mm	0.079 in	UL94 V-0	Socket	0.098 in	2.5 mm	Through Hole	Female Socket	-55 C	125 °C	Push-Pull	40	29.5 µin	0.75 µm	0.079 "	2 mm	Press-Fit Solder	Black	0.165 in	4.2 mm	3 A	Gold
