306-017 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CARD EDGE CONNECTOR, SINGLE SIDE, 1.57 MM, 17 CONTACTS, PANEL MOUNT, STRAIGHT
| Part | Material - Insulation | Termination Rows | Gender | Contact Material | Color | Card Thickness [Max] | Card Thickness [Min] | Card Type | Number of Positions/Bay/Row [custom] | Pitch | Pitch | Contact Finish | Operating Temperature [Min] | Operating Temperature [Max] | Read Out | Number of Positions [custom] | Termination | Contact Type | Mounting Type | Number of Rows [custom] | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder Eyelet(s) | Cantilever | Free Hanging (In-Line) | 2 | ||||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Panel Mount Through Hole | 2 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder Eyelet(s) | Cantilever | Panel Mount | 2 | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Panel Mount Through Hole | 2 | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder Eyelet(s) | Cantilever | Panel Mount | 2 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder Eyelet(s) | Cantilever | Panel Mount | 2 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | |||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Gold | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Through Hole | 2 | 0.25 Ám | 10 Áin | ||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Gold | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Panel Mount Through Hole | 2 | Flush Mount Side Opening Unthreaded | 3.25 mm | 0.128 " | 0.25 Ám | 10 Áin | |
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Panel Mount Through Hole | 2 | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 1 | Female | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 17 | 3.96 mm | 0.156 in | Tin | -40 C | 105 ░C | Dual | 34 | Solder | Cantilever | Panel Mount Through Hole | 2 | 4-40 Flush Mount Threaded Insert Top Opening |
