61F Series
Manufacturer: Omron Automation and Safety
Beta
⌘K
CNTRL LIQ LEV 110/220VAC DINRAIL
| Part | Weight | Weight | Distance - Control To Sensor (Max) [Max] | Features | Operating Temperature [Max] | Operating Temperature [Min] | Output Type | Sensitivity [Max] | Sensitivity [Min] | Termination Style | Mounting Type | Type | Contact Form | Contact Rating @ Voltage | Voltage - Supply [Min] | Voltage - Supply [Max] | Voltage - Supply | Termination Style |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Omron Automation and Safety | 410.05 g | 0.904 lb | 2 km | Alarm Low - Contact Idling Prevention | 55 °C | -10 °C | Relay (2) | 1.8 kOhm | 0 kOhm | Screw Terminal | DIN Rail | High/Low Level | SPDT (2 Form C) | 3 A 200 VAC | 110 VAC | 220 VAC | ||
Omron Automation and Safety | 499 g | 1.1 lbs | 1 km | Alarm High/Low - Contact Level Indication | 55 °C | -10 °C | Relay (2) | 1.8 kOhm | 0 kOhm | Plug In 15 Pin (Octal) | Socketable | High/Low Level | SPDT (2 Form C) | 5 A 200 VAC | 220 VAC | |||
 Omron Automation and Safety | Adjustable Sensitivity | 50 °C | -10 °C | Relay | 50 kOhm | 0 kOhm | Plug In | Socketable | Leak Detection | SPDT (2 Form C) | 3 A 250 VAC | 240 VAC | 11 Pin | |||||
 Omron Automation and Safety | 190.06 g | 0.419 lb | 55 °C | -10 °C | 4 kOhm | 0 | Plug In | Socketable | High/Low Level | 120 VAC | ||||||||
 Omron Automation and Safety | 155.13 g | 0.342 lb | 50 m | 55 °C | -10 °C | Relay | 70 kOhm | 15 kOhm | Plug In | Socketable | High/Low Level | SPDT (2 Form C) | 3 A 250 VAC | 120 VAC | ||||
Omron Automation and Safety | 952.5 g | 2.1 lb | 600 m | Alarm High/Low - Contact | 55 °C | -10 °C | Relay (3) | 5 kOhm | 0 | Screw Terminal | Chassis Mount | High/Low Level | SPDT (2 Form C) | 5 A 220 VAC | 110 VAC | 220 VAC | ||
Omron Automation and Safety | 771.1 g | 1.7 lbs | 1 km | Alarm High - Contact | 55 °C | -10 °C | Relay (2) | 4 kOhm | 0 | Screw Terminal | Chassis Mount | High/Low Level | SPDT (1 Form C) SPDT (2 Form C) | 5 A 220 VAC | 100 VAC | 200 VAC | ||
 Omron Automation and Safety | 155.13 g | 0.342 lb | 1 km | 55 °C | -10 °C | Relay | 4 kOhm | 0 | Plug In | Socketable | High/Low Level | SPDT (2 Form C) | 3 A 250 VAC | 120 VAC | 11 Pin | |||
Omron Automation and Safety | 155.13 g | 0.342 lb | 1 km | 55 °C | -10 °C | Relay | 4 kOhm | 0 | Plug In | Socketable | High/Low Level | SPDT (2 Form C) | 3 A 250 VAC | 230 VAC | ||||
Omron Automation and Safety | 410.05 g | 0.904 lb | 1 km | Alarm High - Contact | 55 °C | -10 °C | Relay (2) | 4 kOhm | 0 | Screw Terminal | DIN Rail | High/Low Level | SPDT (1 Form C) SPDT (2 Form C) | 3 A 200 VAC | 110 VAC | 220 VAC |
