D433 Series

Catalog

SWITCH SNAP ACTION SPDT 6A 250V

Part	Operating Force	Operating Position	Operating Position	Features	Voltage Rating - AC	Overtravel [custom]	Overtravel [custom]	Operating Temperature [Max]	Operating Temperature [Min]	Differential Travel	Differential Travel	Circuit	Mounting Type	Pretravel	Pretravel	Electrical Life	Current Rating (Amps)	Termination Style	Actuator Type	Switch Function	Release Force	Differential Travel
ZF Electronics D433-R1RA-G2	194 gf	0.806 in	20.5 mm	Explosion Proof	250 V	1 mm	0.039 "	85 °C	-40 C	0.016 in	0.4 mm	SPDT	Chassis Mount	1.2 mm	0.047 in	50000 Cycles	6 A	Quick Connect	Lever Roller	On-Mom
ZF Electronics D433-R1LD-G2	88 gf	0.6 in	15.2 mm	Explosion Proof	250 V	2.3 mm	0.09 "	85 °C	-40 C	0.031 in	0.8 mm	SPDT	Chassis Mount	3.2 mm	0.125 in	50000 Cycles	6 A	Quick Connect	Lever Straight	On-Mom	20 gf
ZF Electronics D433-R1AA-G2	173 gf	0.579 in	14.7 mm	Explosion Proof	250 V	1.3 mm	0.051 "	85 °C	-40 C	0.012 in	0.3 mm	SPDT	Chassis Mount	1.2 mm	0.047 in	50000 Cycles	6 A	Quick Connect	Round (Pin Plunger)	On-Mom	46 gf
ZF Electronics D433-R1TD				Explosion Proof	250 V	3.6 mm	0.141 "	85 °C	-40 C		0.05 in	SPDT	Chassis Mount	5.1 mm	0.2 in	50000 Cycles	6 A	Quick Connect	Lever Roller	On-Mom		1.3 mm
ZF Electronics D433-R1RD	88 gf	0.806 in	20.5 mm	Explosion Proof	250 V	2.2 mm	0.087 "	85 °C	-40 C	0.03 in	0.76 mm	SPDT	Chassis Mount	3.2 mm	0.125 in	50000 Cycles	6 A	Quick Connect	Lever Roller	On-Mom	20 gf
