M402VF Series

Catalog

CONN RCPT 10POS SMD TIN

Part	Pitch	Pitch	Mounting Type	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Number of Positions	Mated Stacking Heights	Height Above Board [z]	Height Above Board [z]	Contact Finish	Number of Rows [custom]	Features	Height Above Board	Height Above Board
Harwin Inc. M402VF-3-010-03NR	0.02 "	0.5 mm	Surface Mount	1.3 Ám	51.2 Áin	Receptacle Outer Shroud Contacts	10	3 mm	0.098 in	2.5 mm	Tin	2	Board Guide Pick and Place Solder Retention
Harwin Inc. M402VF-3-080-03NR	0.02 "	0.5 mm	Surface Mount	1.3 Ám	51.2 Áin	Receptacle Outer Shroud Contacts	80	3 mm	0.098 in	2.5 mm	Tin	2	Board Guide Pick and Place Solder Retention
Harwin Inc. M402VF-3-030-05NR	0.02 "	0.5 mm	Surface Mount	1.3 Ám	51.2 Áin	Receptacle Outer Shroud Contacts	30	5 mm	0.157 in	4 mm	Tin	2	Board Guide Pick and Place Solder Retention
Harwin Inc. M402VF-3-016-02NR	0.02 "	0.5 mm	Surface Mount	1.3 Ám	51.2 Áin	Receptacle Outer Shroud Contacts	16	2.5 mm			Tin	2	Board Guide Pick and Place Solder Retention	2 mm	0.079 in
