MAX309 Series

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

IC SWITCH SP4TX2 100OHM 16TSSOP

Part	Package / Case [x]	Package / Case	Package / Case [y]	Number of Circuits	Operating Temperature [Max]	Operating Temperature [Min]	Supplier Device Package	Charge Injection	Channel Capacitance (CS(off), CD(off)) [custom]	Channel Capacitance (CS(off), CD(off)) [custom]	Mounting Type	Voltage - Supply, Single (V+) [Min]	Voltage - Supply, Single (V+) [Max]	Switch Time (Ton, Toff) (Max) [custom]	Switch Time (Ton, Toff) (Max) [custom]	Crosstalk	On-State Resistance (Max) [Max]	Switch Circuit	Voltage - Supply, Dual (V±) [Max]	Voltage - Supply, Dual (V±) [Min]	Current - Leakage (IS(off)) (Max) [Max]	Multiplexer/Demultiplexer Circuit	Channel-to-Channel Matching (ΔRon)	Package / Case	Package / Case	Package / Case
Analog Devices Inc./Maxim Integrated MAX309EUE	0.173 in	16-TSSOP	4.4 mm	2	85 °C	-40 °C	16-TSSOP	2 pC	3 pF	14 pF	Surface Mount	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T - Open/Closed	20 V	-5 V	750 pA	4:1	1.5 Ohm
Analog Devices Inc./Maxim Integrated MAX309CSE	0.154 in	16-SOIC	3.9 mm	2	70 °C	0 °C	16-SOIC	2 pC	3 pF	26 pF	Surface Mount	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm
Analog Devices Inc./Maxim Integrated MAX309ESE+T	0.154 in	16-SOIC	3.9 mm	2	85 °C	-40 °C	16-SOIC	2 pC	3 pF	26 pF	Surface Mount	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm
Analog Devices Inc./Maxim Integrated MAX309CPE+		16-DIP		2	70 °C	0 °C	16-PDIP	2 pC	3 pF	26 pF	Through Hole	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm	0.3 in	7.62 mm
Analog Devices Inc./Maxim Integrated MAX309ESE+	0.154 in	16-SOIC	3.9 mm	2	85 °C	-40 °C	16-SOIC	2 pC	3 pF	26 pF	Surface Mount	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm
Analog Devices Inc./Maxim Integrated MAX309CPE+G126
Analog Devices Inc./Maxim Integrated MAX309CPE		16-DIP		2	70 °C	0 °C	16-PDIP	2 pC	3 pF	26 pF	Through Hole	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm	0.3 in	7.62 mm
Analog Devices Inc./Maxim Integrated MAX309EJE		16-CDIP		2	85 °C	-40 °C	16-CERDIP	2 pC	3 pF	14 pF	Through Hole	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T - Open/Closed	20 V	-5 V	750 pA	4:1	1.5 Ohm			0.3 in 7.62 mm
Analog Devices Inc./Maxim Integrated MAX309EUE+	0.173 in	16-TSSOP	4.4 mm	2	85 °C	-40 °C	16-TSSOP	2 pC	3 pF	26 pF	Surface Mount	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm
Analog Devices Inc./Maxim Integrated MAX309EPE+		16-DIP		2	85 °C	-40 °C	16-PDIP	2 pC	3 pF	26 pF	Through Hole	5 V	30 V	150 ns	150 ns	-92 dB	100 Ohms	SP4T	20 V	-5 V	750 pA	4:1	1.5 Ohm	0.3 in	7.62 mm
