190-009 Series
Manufacturer: NorComp Inc.
Beta
⌘K
CONN D-SUB PLUG 9P SMD R/A SLDR
| Part | Voltage Rating | Contact Material | Dielectric Material | Color | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Rows [custom] | Shell Material, Finish | Current Rating (Amps) | Contact Finish Thickness | Contact Finish | Features | Termination | Connector Style | Connector Type | Number of Positions | Contact Type | Mounting Type | Flange Feature | Flange Feature | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 NorComp Inc. | 300 VDC | Phosphor Bronze | Polyamide (PA6T) Nylon 6T | Black | 1 | DE E | 2 | Steel | 5 A | Flash | Gold | Board Guide Board Lock Grounding Indents Shielded | Solder | D-Sub | Plug Male Pins | 9 | Signal | Board Edge Right Angle Surface Mount | Housing/Shell | 4-40 | UL94 V-0 | ||||
NorComp Inc. | 300 VDC | Phosphor Bronze | Polyamide (PA6T) Nylon 6T | Black | 1 | DE E | 2 | Steel | 5 A | Flash | Gold | Board Guide Board Lock | Solder | D-Sub | Receptacle Female Sockets | 9 | Signal | Board Edge Right Angle Surface Mount | Housing/Shell | 4-40 | UL94 V-0 | ||||
 NorComp Inc. | 300 VDC | Phosphor Bronze | Polyamide (PA6T) Nylon 6T | Black | 1 | DE E | 2 | Nickel Plated Steel | 5 A | Flash | Gold | Board Guide Board Lock Grounding Indents Shielded | Solder | D-Sub | Plug Male Pins | 9 | Signal | Board Edge Right Angle Surface Mount | Housing/Shell | 4-40 | UL94 V-0 | -55 C | 105 ░C | ||
 NorComp Inc. | 250 V | Brass | Polybutylene Terephthalate (PBT) | Black | 1 | DE E | 2 | Nickel Plated Steel | 3 A | Gold | Board Lock | Solder | D-Sub | Receptacle Female Sockets | 9 | Signal | Panel Mount Right Angle Through Hole | Housing/Shell | 4-40 | UL94 V-0 | -55 C | 85 °C | 30 Áin | 0.76 Ám | |
 NorComp Inc. | 250 V | Brass | Polybutylene Terephthalate (PBT) | Black | 1 | DE E | 2 | Nickel Plated Steel | 3 A | Gold | Board Lock Grounding Indents | Solder | D-Sub | Plug Male Pins | 9 | Signal | Panel Mount Right Angle Through Hole | Housing/Shell (Unthreaded) | UL94 V-0 | -55 C | 85 °C | 30 Áin | 0.76 Ám | ||
 NorComp Inc. | 300 VDC | Phosphor Bronze | Polyamide (PA6T) Nylon 6T | Black | 1 | DE E | 2 | Nickel Plated Steel | 5 A | Flash | Gold | Board Guide Board Lock Shielded | Solder | D-Sub | Receptacle Female Sockets | 9 | Signal | Board Edge Right Angle Surface Mount | Housing/Shell | 4-40 | UL94 V-0 | -55 C | 105 ░C | ||
 NorComp Inc. | 250 V | Brass | Polybutylene Terephthalate (PBT) | Black | 1 | DE E | 2 | Nickel Plated Steel | 3 A | Flash | Gold | Board Lock Grounding Indents | Solder | D-Sub | Plug Male Pins | 9 | Signal | Panel Mount Right Angle Through Hole | 4-40 Mating Side Female Screwlock | UL94 V-0 | -55 C | 85 °C |
