LCDX2 Series

Catalog

CONN TERM RECT TONG 2 AWG #1/4

Part	Contact Finish	Diameter - Barrel OD [diameter]	Diameter - Barrel OD [diameter]	Contact Material	Diameter - Ring ID	Diameter - Ring ID	Diameter - Barrel ID [diameter]	Diameter - Barrel ID [diameter]	Width - Outer Edges	Width - Outer Edges	Color	Stud/Tab Size	Terminal Type	Terminal Style	Wire Gauge	Insulation	Termination	Tab Thickness	Tab Thickness	Mounting Type	Diameter - Ring ID	Length - Overall [x]	Length - Overall [x]	Wire Gauge	Width - Outer Edges [x]	Length - Overall	Length - Overall
Panduit Corp LCDX2-14DF-E	Electro-Tin	0.47 "	11.94 mm	Copper	0.27 in	6.86 mm	0.36 in	9.14 mm	0.7 "	17.78 mm	Brown	0.25 Stud	Rectangular Tongue	Two Stud Holes	2 AWG	Non-Insulated	Barrel Crimp	0.11 in	2.79 mm	Free Hanging (In-Line) Right Angle
Panduit Corp LCDX250-12-X	Electro-Tin	0.88 in	22.35 mm	Copper		0.53 in	0.7 in	17.78 mm		32.51 mm	Yellow	0.5 Stud	Rectangular Tongue	Two Stud Holes	250 kcmil	Non-Insulated	Barrel Crimp	0.17 in	4.32 mm	Free Hanging (In-Line)	13.46 mm	115.57 mm	4.55 in	250 kcmil	1.28 "
Panduit Corp LCDX2-56D-E	Electro-Tin	0.47 "	11.94 mm	Copper		0.34 in	0.36 in	9.14 mm	0.7 "	17.78 mm	Brown	0.3125 Stud	Rectangular Tongue	Two Stud Holes	2 AWG	Non-Insulated	Barrel Crimp	0.11 in	2.79 mm	Free Hanging (In-Line)	8.64 mm	66.8 mm	2.63 in
Panduit Corp LCDX2-14B-E	Electro-Tin	0.47 "	11.94 mm	Copper	0.27 in	6.86 mm	0.36 in	9.14 mm	0.7 "	17.78 mm	Brown	0.25 Stud	Rectangular Tongue	Two Stud Holes	2 AWG	Non-Insulated	Barrel Crimp	0.11 in	2.79 mm	Free Hanging (In-Line)						2.25 "	57.15 mm
Panduit Corp LCDX2-14D-E	Electro-Tin	0.47 "	11.94 mm	Copper	0.27 in	6.86 mm	0.36 in	9.14 mm	0.7 "	17.78 mm	Brown	0.25 Stud	Rectangular Tongue	Two Stud Holes	2 AWG	Non-Insulated	Barrel Crimp	0.11 in	2.79 mm	Free Hanging (In-Line)		63.5 mm	2.5 "
Panduit Corp LCDX2-14AH-E	Electro-Tin	0.47 "	11.94 mm	Copper	0.27 in	6.86 mm	0.36 in	9.14 mm	0.7 "	17.78 mm	Brown	0.25 Stud	Rectangular Tongue	Two Stud Holes	2 AWG	Non-Insulated	Barrel Crimp	0.11 in	2.79 mm	Free Hanging (In-Line)
Panduit Corp LCDX250-12EF-X	Electro-Tin	0.88 in	22.35 mm	Copper		0.53 in	0.7 in	17.78 mm		32.51 mm	Yellow	0.5 Stud	Rectangular Tongue	Two Stud Holes	250 kcmil	Non-Insulated	Barrel Crimp	0.17 in	4.32 mm	Free Hanging (In-Line) Right Angle	13.46 mm			250 kcmil	1.28 "
