M80-790 Series

Catalog

3 POS. FEMALE SIL VERTICAL THROUGHBOARD CONN. FOR LATCHES ROHS COMPLIANT: YES

Part	Insulation Material	Contact Shape	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Applications	Contact Material	Fastening Type	Style	Termination	Number of Rows	Contact Finish - Post	Contact Finish - Mating	Number of Positions Loaded	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Insulation Color	Pitch - Mating	Pitch - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Post	Contact Length - Post	Mated Stacking Heights	Contact Type	Voltage Rating	Material Flammability Rating	Connector Type	Insulation Height	Insulation Height	Number of Positions
Harwin Inc. M80-7900342	Glass Filled Nylon 4/6 Polyamide (PA46)	Circular	3.5 Ám	137.8 Áin	Automotive General Purpose Military	Beryllium Copper	Locking Ramp	Board to Board Cable	Solder	1	Tin	Gold	All	-55 C	125 °C	Through Hole	Black	0.079 "	2 mm	12 Áin	0.3 Ám	4.5 mm	0.177 in	7.23 mm 7.83 mm	Female Socket	120 VDC	UL94 V-0	Receptacle	0.202 in	5.14 mm
Harwin Inc. M80-7900545	Glass Filled Nylon 4/6 Polyamide (PA46)	Circular	0.25 çm	10 Áin	Automotive General Purpose Military	Beryllium Copper	Locking Ramp	Board to Board Cable	Solder	1	Gold	Gold	All	-55 C	125 °C	Through Hole	Black	0.079 "	2 mm	12 Áin	0.3 Ám	4.5 mm	0.177 in	7.23 mm 7.83 mm	Female Socket	120 VDC	UL94 V-0	Receptacle	0.202 in	5.14 mm	5
Harwin Inc. M80-7900345	Glass Filled Nylon 4/6 Polyamide (PA46)	Circular	0.25 çm	10 Áin	Automotive General Purpose Military	Beryllium Copper	Locking Ramp	Board to Board Cable	Solder	1	Gold	Gold	All	-55 C	125 °C	Through Hole	Black	0.079 "	2 mm	12 Áin	0.3 Ám	4.5 mm	0.177 in	7.23 mm 7.83 mm	Female Socket	120 VDC	UL94 V-0	Receptacle	0.202 in	5.14 mm
