751265 Series

Catalog

HU WIRE XLPE /1000 FT /EACH

Part	Voltage	Wire Gauge	Conductor Material	Length	Length	Operating Temperature [Max]	Operating Temperature [Min]	Jacket Color	Cable Type	Conductor Strand [custom]	Conductor Strand [custom]	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
ALPHA WIRE 751265 BR001	600 V	12 AWG	Copper Tinned	304.8 m	1000 ft	125 °C	-40 C	Brown	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
ALPHA WIRE 751265 YL001	600 V	12 AWG	Copper Tinned	304.8 m	1000 ft	125 °C	-40 C	Yellow	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
ALPHA WIRE 751265 RD001	600 V	12 AWG	Copper Tinned	304.8 m	1000 ft	125 °C	-40 C	Red	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
ALPHA WIRE 751265 GY001				304.8 m	1000 ft
ALPHA WIRE 751265 SL001	600 V	12 AWG	Copper Tinned	304.8 m	1000 ft	125 °C	-40 C	Slate	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
ALPHA WIRE 751265 WH002	600 V	12 AWG	Copper Tinned	152.4 m	500 ft	125 °C	-40 C	White	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
ALPHA WIRE 751265 GR005	600 V	12 AWG	Copper Tinned			125 °C	-40 C	Green	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm	100 ft	30.5 m
ALPHA WIRE 751265 WH001	600 V	12 AWG	Copper Tinned	304.8 m	1000 ft	125 °C	-40 C	White	Hook-Up	30 AWG	65	UL Style 3173	0.8 mm	0.031 in	Polyethylene (XLPE) Irradiated	0.155 in	3.94 mm
