073420 Series
Manufacturer: Molex
Beta
⌘K
SMP-MAX PLUG PRESS IN RECEP CATC
| Part | Center Contact Plating | Body Material | Frequency - Max [Max] | Impedance | Dielectric Material | Contact Termination | Shield Termination | Connector Type | Mounting Type | Fastening Type | Voltage Rating | Number of Ports | Body Finish | Center Contact Material | Housing Color | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Molex | Gold | Brass | 6000 MHz | 50 Ohms | Polytetrafluoroethylene (PTFE) | Solder | Solder | Male Pin Plug | Through Hole | Snap-On | 300 VDC | 1 | Gold | Brass | Gold | |
Molex | Gold | Brass | 6000 MHz | 50 Ohms | Polyetheretherketone (PEEK) Polytetrafluoroethylene (PTFE) | Solder | Solder | Male Pin Plug | Board Edge Cutout Surface Mount | Snap-On | 330 VDC | 1 | Gold | Brass | Gold | |
 Molex | ||||||||||||||||
Molex | Gold | Brass | 6000 MHz | 50 Ohms | Polytetrafluoroethylene (PTFE) | Solder | Solder | Male Pin Plug | 330 VDC | 1 | Gold | Brass | Gold | Extended Insulation | ||
Molex | Gold | Brass | 6000 MHz | 50 Ohms | Polytetrafluoroethylene (PTFE) | Solder | Solder | Male Pin Plug | Through Hole | Snap-On | 330 VDC | 1 | Gold | Brass | Gold | |
Molex | ||||||||||||||||
 Molex | Gold | Brass | 6000 MHz | 50 Ohms | Liquid Crystal Polymer (LCP) Polyetheretherketone (PEEK) Polytetrafluoroethylene (PTFE) | Solder | Solder | Male Pin Plug | Surface Mount Through Hole | Snap-On | 330 VDC | 1 | Gold | Brass | Gold | |
 Molex | ||||||||||||||||
 Molex | Gold | Brass | 6000 MHz | 50 Ohms | Polytetrafluoroethylene (PTFE) | Solder | Solder | Female Socket Jack | Surface Mount | Snap-On | 300 VDC | 1 | Gold | Beryllium Copper | Gold | |
Molex | Gold | Brass | 10 GHz | 50 Ohms | Liquid Crystal Polymer (LCP) | Solder | Solder | Male Pin Plug | Surface Mount | Snap-On | 330 VDC | 1 | Gold | Brass | Gold |
