846-025 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 25POS 0.125
| Part | Material - Insulation | Termination Rows | Number of Positions/Bay/Row | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Number of Rows | Pitch | Pitch | Mounting Type | Contact Finish | Gender | Color | Read Out | Termination | Card Type | Number of Positions | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Operating Temperature [Max] | Operating Temperature [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Wire Wrap | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | 1 | 3.18 mm | 0.125 in | Right Angle Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 0.128 " | 3.25 mm | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | |||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 4-40 Threaded Insert Top Mount Opening | 1 | 3.18 mm | 0.125 in | Right Angle Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 0.156 " | 3.96 mm | 1 | 3.18 mm | 0.125 in | Right Angle Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C |
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder Eyelet(s) | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C | ||
 EDAC Inc. | Diallyl Phthalate (DAP) | 1 | 25 | Copper Alloy | 0.128 " | 3.25 mm | 1 | 3.18 mm | 0.125 in | Through Hole | Gold | Female | Green | Single | Solder | Non Specified - Single Edge | 25 | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 125 °C | -40 C |
