395-010 Series
Manufacturer: EDAC Inc.
Catalog
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Contact Material | Card Type | Number of Rows | Contact Finish | Termination Rows | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Color | Contact Type | Gender | Number of Positions/Bay/Row [custom] | Contact Finish Thickness | Contact Finish Thickness | Read Out | Material - Insulation | Number of Positions | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch [x] | Pitch [x] | Termination | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Flange Feature | Flange Feature | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Solder | M3 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Copper Alloy | Non Specified - Dual Edge | 2 | Gold | 2 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 5 | 10 Áin | 0.25 Ám | Dual | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Solder | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole Right Angle | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Solder | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in | |||
EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Wire Wrap | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Copper Alloy | Non Specified - Dual Edge | 2 | Gold | 2 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 5 | 10 Áin | 0.25 Ám | Dual | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Wire Wrap | 3.25 mm | 0.128 in | ||||
EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Wire Wrap | 4-40 Threaded Insert Top Mount Opening | |||||
EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Wire Wrap | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in | |||
 EDAC Inc. | Copper Alloy | Non Specified - Single Edge | 1 | Gold | 1 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 10 | 10 Áin | 0.25 Ám | Single | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Solder | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||||
 EDAC Inc. | Copper Alloy | Non Specified - Dual Edge | 2 | Gold | 2 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 5 | 10 Áin | 0.25 Ám | Dual | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Solder | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||||
 EDAC Inc. | Copper Alloy | Non Specified - Dual Edge | 2 | Gold | 2 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | Black | Cantilever | Female | 5 | 10 Áin | 0.25 Ám | Dual | Polyester Thermoplastic | 10 | Through Hole | -40 °C | 105 ░C | 2.54 mm | 0.1 in | Wire Wrap | 4-40 Threaded Insert Top Mount Opening |
