307-022 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 22POS 0.156
| Part | Material - Insulation | Termination Rows [custom] | Pitch | Pitch | Number of Positions/Bay/Row | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Gender | Number of Rows [custom] | Mounting Type | Color | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Finish Thickness | Contact Finish Thickness | Read Out | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Contact Material | Termination | Card Type | Contact Finish | Features | Termination Rows | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 11 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | Right Angle Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Dual | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | Copper Alloy | Solder | Non Specified - Dual Edge | Gold | |||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 11 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | Board Edge Straddle Mount | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Solder | Non Specified - Dual Edge | Gold | Card Extender Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Right Angle Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Single | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Copper Alloy | Solder | Non Specified - Single Edge | Gold | 1 | 1 | |||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | Right Angle Through Hole | Green | -40 C | 105 ░C | 44 | 0.25 Ám | 10 Áin | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Gold | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Single | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Gold | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | Through Hole | Green | -40 C | 105 ░C | 44 | Dual | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Copper Alloy | Wire Wrap | Non Specified - Dual Edge | Tin | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Right Angle Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Single | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Solder | Non Specified - Single Edge | Gold | 1 | 1 | |||||
 EDAC Inc. | Polyester Thermoplastic | 2 | 3.96 mm | 0.156 in | 11 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | 2 | Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Dual | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Solder | Non Specified - Dual Edge | Gold | Card Guides | ||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Single | 4-40 Flush Mount Threaded Insert Top Opening | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Gold | Card Guides | 1 | 1 | ||||
 EDAC Inc. | Polyester Thermoplastic | 3.96 mm | 0.156 in | 22 | Semi Bellows | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Female | Through Hole | Green | -40 C | 105 ░C | 22 | 0.25 Ám | 10 Áin | Single | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Copper Alloy | Wire Wrap | Non Specified - Single Edge | Gold | 1 | 1 |
