333-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 24POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions | Gender | Card Thickness [Max] | Card Thickness [Min] | Number of Rows | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Color | Contact Material | Flange Feature [diameter] | Flange Feature [diameter] | Card Type | Termination | Contact Finish | Number of Positions/Bay/Row | Pitch | Pitch | Contact Finish Thickness | Contact Finish Thickness | Read Out | Mounting Type | Termination Rows [custom] | Flange Feature | Features | Number of Rows [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.156 " | 3.96 mm | Non Specified - Single Edge | Wire Wrap | Gold | 24 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Single | Through Hole | ||||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | Non Specified - Dual Edge | Solder | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Board Edge Straddle Mount | 2 | Flush Mount M3 Threaded Insert Top Opening | Card Extender | 2 | ||||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Solder | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Board Edge Straddle Mount | 2 | Flush Mount Top Opening Unthreaded | Card Extender | 2 | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Single Edge | Wire Wrap | Gold | 24 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Single | Through Hole | Flush Mount Side Opening Unthreaded | |||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.116 " | 2.95 mm | Non Specified - Dual Edge | Solder | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Right Angle Through Hole | 2 | Floating Bobbin Flush Mount | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Single Edge | Solder | Gold | 24 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Single | Right Angle Through Hole | Flush Mount Side Opening Unthreaded | |||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Wire Wrap | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Through Hole | 2 | Flush Mount Top Opening Unthreaded | 2 | |||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Wire Wrap | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Right Angle Through Hole | 2 | Flush Mount Top Opening Unthreaded | 2 | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | Non Specified - Single Edge | Solder Eyelet(s) | Gold | 24 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Single | Through Hole | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Polyester Thermoplastic | 24 | Female | 0.07 in 1.78 mm | 0.054 in 1.37 mm | -40 C | 105 ░C | Cantilever | Green | Copper Alloy | 0.128 " | 3.25 mm | Non Specified - Dual Edge | Solder | Gold | 12 | 3.96 mm | 0.156 in | 0.25 Ám | 10 Áin | Dual | Through Hole | 2 | Flush Mount Side Opening Unthreaded | 2 |
