74164 Series
Manufacturer: Molex
Beta
⌘K
2.54MM PITCH C-GRID RECEPTACLE, RIGHT-ANGLE, THROUGH HOLE, DUAL ROW, SHROUDED WITH PEGS HIGH-TEMPERATURE, 50 CIRCUITS, TIN (SN)
| Part | Applications | Contact Type | Contact Material | Contact Length - Mating | Contact Length - Mating | Contact Shape | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Insulation Height [custom] | Insulation Height [custom] | Insulation Color | Contact Finish - Post | Connector Type | Shrouding | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Mounting Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Material Flammability Rating | Number of Rows | Features | Row Spacing - Mating [x] | Row Spacing - Mating [x] | Number of Positions | Contact Length - Post | Contact Length - Post | Termination | Fastening Type | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Molex | |||||||||||||||||||||||||||||||
Molex | Automotive General Purpose Lighting Medical Telecommunications | Male Pin | Copper Alloy | 8 mm | 0.315 in | Square | Gold | 0.1 in | 2.54 mm | 0.42 in | 10.67 mm | Black | Tin | Receptacle | Shrouded - 4 Wall | 15 µin | 0.38 µm | Through Hole Right Angle | 74.8 Áin | 1.9 Ám | UL94 V-0 | 2 | Board Guide | 2.54 mm | 0.1 in | 24 | 0.13 in | 3.3 mm | Solder | Latch Holder | All |
