896-031 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 31POS 0.125
| Part | Termination Rows | Material - Insulation | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Mounting Type | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Pitch | Pitch | Color | Read Out | Contact Material | Termination | Gender | Number of Positions/Bay/Row [custom] | Number of Positions [custom] | Card Thickness [Max] | Card Thickness [Min] | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | 0.128 " | 3.25 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Wire Wrap | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | 0.128 " | 3.25 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder Eyelet(s) | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | 4-40 Threaded Insert Top Mount Opening | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Wire Wrap | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder Eyelet(s) | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Right Angle Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Wire Wrap | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | Gold | 0.25 Ám | 10 Áin | Through Hole | 125 °C | -40 C | Non Specified - Single Edge | Flush Mount M3 Threaded Insert Top Opening | Cantilever | 3.18 mm | 0.125 in | Black | Single | Copper Alloy | Solder Eyelet(s) | Female | 31 | 31 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 |
