833-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Gender | Number of Rows [custom] | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Features | Pitch | Pitch | Contact Type | Card Thickness [Max] | Card Thickness [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions | Read Out | Termination | Mounting Type | Card Type | Color | Number of Positions/Bay/Row | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Card Extender | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Board Edge Straddle Mount | Non Specified - Dual Edge | Green | 26 | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Wire Wrap | Through Hole | Non Specified - Dual Edge | Green | 26 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Wire Wrap | Through Hole | Non Specified - Dual Edge | Green | 26 | 4-40 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Right Angle Through Hole | Non Specified - Dual Edge | Green | 26 | 4-40 Flush Mount Threaded Insert Top Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Card Extender | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Board Edge Straddle Mount | Non Specified - Dual Edge | Green | 26 | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Through Hole | Non Specified - Dual Edge | Green | 26 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Through Hole | Non Specified - Dual Edge | Green | 26 | M3 Threaded Insert Top Mount Opening | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Right Angle Through Hole | Non Specified - Dual Edge | Green | 26 | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | Card Extender | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Solder | Board Edge Straddle Mount | Non Specified - Dual Edge | Green | 26 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Female | 2 | Copper Alloy | 0.25 Ám | 10 Áin | Gold | 3.96 mm | 0.156 in | Cantilever | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 125 °C | -40 C | 52 | Dual | Wire Wrap | Through Hole | Non Specified - Dual Edge | Green | 26 | 0.116 " | Floating Bobbin Top Mount Opening | 2.95 mm |
