Coupled Inductors IND BIGFOOT
Coupled Inductors IND BIGFOOT
| Part | Current Rating - Parallel | Tolerance | Inductance - Connected In Series | Package / Case | Number of Coils | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | DC Resistance (DCR) - Series [Max] | DC Resistance (DCR) - Parallel | Shielding | Height | Height | Mounting Type | Current Rating - Series | Operating Temperature [Max] | Operating Temperature [Min] | Inductance - Connected In Parallel | DC Resistance (DCR) - Series | DC Resistance (DCR) - Parallel [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Pulse Electronics | 38 A | 15 % | 8.4 µH | Nonstandard | 2 | 1 " | 25.4 mm | 1.22 in | 30.99 mm | 5.1 mOhm | 1.3 mOhm | Unshielded | 12.7 mm | 0.5 in | Surface Mount | 19 A | 130 °C | -40 C | 2.1 µH | ||
Pulse Electronics | 34 A | 15 % | 15.6 µH | Nonstandard | 2 | 1 " | 25.4 mm | 1.22 in | 30.99 mm | Unshielded | 12.7 mm | 0.5 in | Surface Mount | 17 A | 130 °C | -40 C | 3.9 µH | 6.4 mOhm | 1.6 mOhm | ||
Pulse Electronics | 38 A | 15 % | 8.4 µH | Nonstandard | 2 | 1 " | 25.4 mm | 1.22 in | 30.99 mm | 5.1 mOhm | 1.3 mOhm | Unshielded | 12.7 mm | 0.5 in | Surface Mount | 19 A | 130 °C | -40 C | 2.1 µH |
