KSA0V3 Series

Catalog

SWITCH TACTILE SPST-NO 0.01A 50V

Part	Outline [x]	Outline [y]	Operating Force	Mounting Type	Ingress Protection	Circuit	Switch Function	Actuator Type	Operating Temperature [Max]	Operating Temperature [Min]	Actuator Length, Right Angle [x]	Actuator Orientation	Illumination	Termination Style	Contact Rating @ Voltage
Littelfuse/Commercial Vehicle Products KSA0V330	7.4 mm	7.4 mm	130 gf	Through Hole Right Angle	IP40	SPST-NO	Off-Mom	Standard	125 °C	-40 °C	3.23 mm	Side Actuated	Non-Illuminated	PC Pin	0.01 A 50 VDC
Littelfuse/Commercial Vehicle Products KSA0V310	7.4 mm	7.4 mm	130 gf	Through Hole Right Angle	IP40	SPST-NO	Off-Mom	Standard	90 °C	-40 °C	3.23 mm	Side Actuated	Non-Illuminated	PC Pin	0.05 A
Littelfuse/Commercial Vehicle Products KSA0V311	8 mm	8 mm	130 gf	Through Hole Right Angle	IP60	SPST-NO	Off-Mom	Standard	90 °C	-40 °C	3.23 mm	Side Actuated	Non-Illuminated	PC Pin	0.05 A
Littelfuse/Commercial Vehicle Products KSA0V311LFT	8 mm	8 mm	130 gf	Through Hole Right Angle	IP60	SPST-NO	Off-Mom	Standard	90 °C	-40 °C	3.23 mm	Side Actuated	Non-Illuminated	PC Pin	0.05 A
