XC6214 Series

Catalog

IC REG LINEAR 3.4V 500MA TO252

Part	Output Configuration	Supplier Device Package	PSRR	Voltage - Output (Min/Fixed)	Mounting Type	Current - Quiescent (Iq)	Voltage - Input (Max) [Max]	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Protection Features	Number of Regulators	Current - Output	Voltage - Output (Min/Fixed) [Min]
Torex Semiconductor Ltd XC6214P342JR-G	Positive	TO-252	40 dB	3.4 V	Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA
Torex Semiconductor Ltd XC6214P292JR-G	Positive	TO-252	40 dB		Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA	2.9 V
Torex Semiconductor Ltd XC6214P262PR-G	Positive		40 dB		Surface Mount	15 µA	6 V	TO-243AA	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA	2.6 V
Torex Semiconductor Ltd XC6214P132JR-G	Positive	TO-252	40 dB		Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA	1.3 V
Torex Semiconductor Ltd XC6214P262JR-G	Positive	TO-252	40 dB		Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA	2.6 V
Torex Semiconductor Ltd XC6214P482JR-G	Positive	TO-252	40 dB	4.8 V	Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA
Torex Semiconductor Ltd XC6214P212PR-G	Positive		40 dB	2.1 V	Surface Mount	15 µA	6 V	TO-243AA	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA
Torex Semiconductor Ltd XC6214P232PR-G	Positive		40 dB	2.3 V	Surface Mount	15 µA	6 V	TO-243AA	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA
Torex Semiconductor Ltd XC6214P322PR-G	Positive		40 dB	3.2 V	Surface Mount	15 µA	6 V	TO-243AA	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA
Torex Semiconductor Ltd XC6214P142JR-G	Positive	TO-252	40 dB		Surface Mount	15 µA	6 V	DPAK (2 Leads + Tab) SC-63 TO-252-3	85 C	-40 ¯C	Over Current Over Temperature	1	500 mA	1.4 V
