CT418 Series

Catalog

XTREMESENSE TMR ULTRA-LOW NOISE,

Part	Polarization	Current - Sensing	Accuracy	Response Time	For Measuring	Number of Channels [custom]	Sensor Type	Voltage - Supply [Max]	Voltage - Supply [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Current - Supply (Max) [Max]	Sensitivity	Linearity	Mounting Type	Supplier Device Package	Output	Frequency [Max]	Frequency [Min]	Package / Case	Package / Case	Package / Case	Supplied Contents	Interface	Utilized IC / Part	Sensing Range	Contents	Sensing Range [Min]	Sensing Range [Max]
Allegro MicroSystems CT418-HSN850DR	Unidirectional	50 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	80 LSB/°/s	0.2 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CT418-HSN830MR	Bidirectional	30 A	0.5 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	66.7 mV/A	0.1 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CT418-HSN865DR	Unidirectional	65 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	61.5 mV/A	0.2 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CT418-HSN865MR	Bidirectional	65 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	30.8 mV/A	0.2 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CT418-HSN850MR	Bidirectional	50 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	40 mV/g	0.1 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CTD418-50DC							Current Sensor	5.5 V	4.75 V				80 LSB/°/s										Board(s)	Analog	CT418	50 A	Board(s)
Allegro MicroSystems CT418-HSN820DR	Unidirectional	20 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	200 mV/A	0.2 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CTD418-50AC							Current Sensor	5.5 V	4.75 V				40 mV/g										Board(s)	Analog	CT418		Board(s)	-50 A	50 A
Allegro MicroSystems CT418-HSN820MR	Bidirectional	20 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	100 mV/g	0.1 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
Allegro MicroSystems CT418-HSN830DR	Unidirectional	30 A	1 %	300 ns	AC DC	1	Magnetoresistive	5.5 V	4.75 V	125 °C	-40 C	9 mA	133.3 mV/A	0.1 %	Surface Mount	8-SOIC	Ratiometric Voltage	1 MHz	DC	0.154 in	8-SOIC	3.9 mm
