VO2223 Series
Manufacturer: Vishay Semiconductor Opto Division
Beta
⌘K
1A, 600V, PHOTOTRIAC, THROUGHHOL
| Part | Number of Channels [custom] | Voltage - Off State | Current - DC Forward (If) (Max) [Max] | Static dV/dt (Min) [Min] | Supplier Device Package | Current - Hold (Ih) | Current - LED Trigger (Ift) (Max) [Max] | Voltage - Forward (Vf) (Typ) [Max] | Package / Case | Package / Case | Package / Case | Approval Agency | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Zero Crossing Circuit | Voltage - Isolation | Output Type | Voltage - Forward (Vf) (Typ) | Current - On State (It (RMS)) (Max) [Max] | Voltage - Isolation [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Vishay Semiconductor Opto Division | 1 | 600 V | 50 mA | 600 V/µs | 8-DIP | 25 mA | 10 mA | 1.4 V | 7 Leads 8-DIP | 7.62 mm | 0.3 in | cUR UR VDE | 85 °C | -40 C | Through Hole | 4470 Vrms | Power Triac | ||||
Vishay Semiconductor Opto Division | 1 | 600 V | 50 mA | 210 V/µs | 8-DIP | 25 mA | 10 mA | 7 Leads 8-DIP | 7.62 mm | 0.3 in | cUR UR | 85 °C | -40 C | Through Hole | Power Triac | 1.3 V | 900 mA | 5300 Vrms |
