D2614 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN IC DIP SOCKET 14POS GOLD
| Part | Termination Post Length | Termination Post Length | Current Rating (Amps) | Material Flammability Rating | Contact Resistance | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Type | Type | Type | Number of Positions or Pins (Grid) | Pitch - Post | Pitch - Post | Pitch - Mating | Pitch - Mating | Housing Material | Contact Material - Post [custom] | Termination | Contact Material - Mating | Contact Finish - Post | Features | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | 0.11 in | 2.78 mm | 1 A | UL94 V-0 | 10 mOhm | 5 µm | 196.9 µin | Gold | 0.25 µm | 10 µin | -55 C | 125 °C | 7.62 mm | 0.3 in | DIP | 14 | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Brass | Press-Fit | Beryllium Copper | Tin | Open Frame | Through Hole |
