T597S Series
Manufacturer: KEMET
Beta
⌘K
TANTALUM POLYMER CAPACITOR, 47 ΜF, ± 20%, 6.3 V, S, 0.2 OHM, 1206 [3216 METRIC]
| Part | Package / Case | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Operating Temperature [Min] | Operating Temperature [Max] | Features | Voltage - Rated | Capacitance | ESR (Equivalent Series Resistance) | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Ratings | Mounting Type | Lifetime @ Temp. | Type | Tolerance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 KEMET | 1206 (3216 Metric) | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | -55 C | 125 °C | Automotive | 6.3 VDC | 47 µF | 200 mOhm | 1.2 mm | 0.047 " | AEC-Q200 | Surface Mount | 2000 Hrs | Molded | 20 % |
 KEMET | 1206 (3216 Metric) | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | -55 C | 125 °C | Automotive | 6.3 VDC | 33 ÁF | 200 mOhm | 1.2 mm | 0.047 " | AEC-Q200 | Surface Mount | 2000 Hrs | Molded | 20 % |
 KEMET | 1206 (3216 Metric) | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | -55 C | 125 °C | Automotive | 6.3 VDC | 33 ÁF | 100 mOhm | 1.2 mm | 0.047 " | AEC-Q200 | Surface Mount | 2000 Hrs | Molded | 20 % |
KEMET | 1206 (3216 Metric) | 0.063 " | 0.126 " | 3.2 mm | 1.6 mm | -55 C | 125 °C | Automotive | 6.3 VDC | 47 µF | 100 mOhm | 1.2 mm | 0.047 " | AEC-Q200 | Surface Mount | 2000 Hrs | Molded | 20 % |
