102972 Series

Manufacturer: TE Connectivity AMP Connectors

Catalog

CONN HEADER VERT 22POS 2.54MM

Part	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Post	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows	Shrouding	Contact Finish - Mating	Contact Shape	Contact Length - Post	Contact Length - Post	Contact Type	Insulation Height [z]	Insulation Height [z]	Contact Material	Fastening Type	Pitch - Mating	Pitch - Mating	Overall Contact Length	Overall Contact Length	Style	Insulation Material	Mounting Type	Insulation Color	Number of Positions Loaded	Number of Positions	Contact Length - Mating	Contact Length - Mating	Current Rating (Amps)	Termination	Operating Temperature [Max]	Operating Temperature [Min]	Material Flammability Rating	Connector Type
TE Connectivity AMP Connectors 4-102972-0-22	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	22	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-36	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	36	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-29	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	29	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-23	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	23	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-16	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	16	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-30	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	30	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-02	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	2	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 102972-4	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull	0.1 "	2.54 mm	13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	4	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
TE Connectivity AMP Connectors 4-102972-0-01	2.54 µm	100 µin	Tin-Lead	0.38 µm	15 µin	1	Unshrouded	Gold	Square	0.125 in	3.18 mm	Male Pin	0.09 in	2.29 mm	Copper Alloy	Push-Pull			13.55 mm	0.533 in	Board to Board Cable	Thermoplastic	Through Hole	Black	All	1	8.08 mm	0.318 in	3 A	Solder	105 ░C	-65 ░C	UL94 V-0	Header Breakaway
