1761614 Series

Board to Board & Mezzanine Connectors STEP-Z RCPT 05MM

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

Board to Board & Mezzanine Connectors STEP-Z RCPT 05MM

Catalog

Board to Board & Mezzanine Connectors STEP-Z RCPT 05MM

Part	Height Above Board	Height Above Board	Connector Type	Contact Finish	Pitch [x]	Pitch [x]	Mounting Type	Number of Positions	Number of Positions [custom]	Contact Finish Thickness	Contact Finish Thickness	Number of Rows [custom]	Mated Stacking Heights	Height Above Board [z]	Height Above Board [z]
TE Connectivity Raychem Cable Protection 1-1761614-3	0.549 in	13.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	18 mm 24 mm 28 mm
TE Connectivity Raychem Cable Protection 2-1761614-5	1.022 "	25.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	30 mm 36 mm 40 mm
TE Connectivity Raychem Cable Protection 6-1761614-3	0.549 in	13.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	18 mm 24 mm 28 mm
TE Connectivity Raychem Cable Protection 6-1761614-2	0.51 in	12.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	17 mm 23 mm 27 mm
TE Connectivity Raychem Cable Protection 6-1761614-0	0.431 in	10.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	15 mm 21 mm 25 mm
TE Connectivity Raychem Cable Protection 8-1761614-5	0.51 in	12.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	17 mm 23 mm 27 mm
TE Connectivity Raychem Cable Protection 7-1761614-0			Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	25 mm 31 mm 35 mm	20.95 mm	0.825 in
TE Connectivity Raychem Cable Protection 2-1761614-0			Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	25 mm 31 mm 35 mm	20.95 mm	0.825 in
TE Connectivity Raychem Cable Protection 6-1761614-5	0.628 in	15.95 mm	Differential Pair Array Male	Gold	1.3 mm	0.051 in	Surface Mount	200	100	0.76 Ám	30 Áin	18	20 mm 26 mm 30 mm
