M80-837 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN HEADER SMD R/A 3POS 2MM
| Part | Insulation Material | Pitch - Mating | Pitch - Mating | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Number of Positions Loaded | Contact Finish - Post | Mounting Type | Termination | Contact Type | Style | Current Rating (Amps) | Contact Shape | Features | Shrouding | Insulation Height [z] | Insulation Height [z] | Voltage Rating | Contact Material | Contact Finish Thickness - Mating [custom] | Contact Finish Thickness - Mating [custom] | Number of Rows | Insulation Color | Material Flammability Rating | Fastening Type | Contact Finish - Mating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | 0.079 " | 2 mm | -55 C | 125 °C | Header | All | Gold | Right Angle Surface Mount | Solder | Male Pin | Board to Board Cable | 2.2 A | Circular | Strain Relief Clips | Shrouded - 4 Wall | 4 mm | 0.157 in | 800 V | Copper Alloy | 29.5 µin | 0.75 µm | 1 | Black | UL94 V-0 | Latch Holder | Gold | |||
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | 0.079 " | 2 mm | -55 C | 125 °C | Header | All | Tin | Right Angle Surface Mount | Solder | Male Pin | Board to Board Cable | 2.2 A | Circular | Strain Relief Clips | Shrouded - 4 Wall | 4 mm | 0.157 in | 800 V | Copper Alloy | 29.5 µin | 0.75 µm | 1 | Black | UL94 V-0 | Latch Holder | Gold | 12 µin | 0.3 µm | 7 |
Harwin Inc. | Polyphenylene Sulfide (PPS) Glass Filled | 0.079 " | 2 mm | -55 C | 125 °C | Header | All | Gold | Right Angle Surface Mount | Solder | Male Pin | Board to Board Cable | 2.2 A | Circular | Strain Relief Clips | Shrouded - 4 Wall | 4 mm | 0.157 in | 800 V | Copper Alloy | 29.5 µin | 0.75 µm | 1 | Black | UL94 V-0 | Latch Holder | Gold | 6 |
