628-W9W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 9P PNL MNT SLDR
| Part | Voltage Rating | Operating Temperature [Max] | Operating Temperature [Min] | Dielectric Material | Contact Material | Color | Connector Style | Shell Material, Finish | Features | Contact Finish Thickness | Contact Finish Thickness | Material Flammability Rating | Current Rating (Amps) | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [x] | Mounting Type | Connector Type | Termination | Flange Feature | Number of Positions [custom] | Number of Positions [custom] | Ingress Protection | Contact Finish | Number of Rows [custom] | Contact Type | Contact Finish Thickness | Current Rating (Amps) | Flange Feature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Board Lock Shielded | 5 µin | 0.127 µm | UL94 V-0 | 10A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Board Side (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Board Lock Shielded | 5 µin | 0.127 µm | UL94 V-0 | 10A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Board Side (4-40) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | UL94 V-0 | 10A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Housing/Shell (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | Flash | |||||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Board Lock Shielded | 5 µin | 0.127 µm | UL94 V-0 | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Board Side (4-40) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | 5 A 30 A | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | UL94 V-0 | 20A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | Flash | ||||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Board Lock Shielded | 5 µin | 0.127 µm | UL94 V-0 | 20A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Board Side (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | 5 µin | 0.127 µm | UL94 V-0 | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | 5 A 30 A | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | 5 µin | 0.127 µm | UL94 V-0 | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Solder | Housing/Shell (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | 5 A 40 A | |||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | UL94 V-0 | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Housing/Shell (M3) | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | Flash | 5 A 40 A | |||||
 EDAC Inc. | 125 VDC | 85 °C | -25 °C | Polybutylene Terephthalate (PBT) Glass Filled | Copper Alloy | Black | Combo D-Sub | Nickel Plated Steel | Shielded | UL94 V-0 | 20A 5A | DB B - 9W4 | 3 | Panel Mount Through Hole | Receptacle Female Sockets | Housing/Shell | 4 | 5 | IP67 - Dust Tight Waterproof | Gold | 2 | Signal and Power | Flash | 4-40 |
