APM49 Series
Manufacturer: UMW
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
MOSFET 30V 5.3A 8SOP
| Part | Vgs(th) (Max) | Rds On (Max) | Power - Max (Ta) | Input Capacitance (Ciss) (Max) | Gate Charge (Max) | Operating Temperature (Min) | Operating Temperature (Max) | Mounting Type | Package Name | Drain to Source Voltage (Vdss) | Package Length | Package Width | Current - Continuous Drain (Id) (Ta) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 UMW | 2.5 V | 41 mOhm | 2 W | 504 pF | 12 nC | -55 °C | 150 °C | Surface Mount | 8-SOIC 8-SOP | 30 V | 0.154 in | 3.9 mm | 5.3 A |
