68604 Series

Catalog

CONN HEADER VERT 15POS 2.54MM

Part	Mounting Type	Insulation Color	Shrouding	Fastening Type	Material Flammability Rating	Contact Shape	Number of Rows	Insulation Height	Insulation Height	Contact Finish - Post	Number of Positions	Overall Contact Length	Overall Contact Length	Contact Length - Mating	Contact Length - Mating	Contact Length - Post [x]	Contact Length - Post [x]	Connector Type	Termination	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Material	Number of Positions Loaded	Contact Type	Current Rating (Amps)	Operating Temperature [Max]	Operating Temperature [Min]	Pitch - Mating	Pitch - Mating	Contact Finish - Mating
Amphenol ICC (FCI) 68604-415HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm	Tin	15	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	2.54 çm	100 çin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm
Amphenol ICC (FCI) 68604-205HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm			0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.38 µm	15 µin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-407HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm	Tin	7	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	2.54 çm	100 çin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm
Amphenol ICC (FCI) 68604-204HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm		4	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.38 µm	15 µin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-232HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm			0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.38 µm	15 µin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-136HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm		36	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.76 Ám	30 Áin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-421HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm	Tin	21	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	2.54 çm	100 çin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm
Amphenol ICC (FCI) 68604-220HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm		20	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.38 µm	15 µin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-104HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm		4	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.76 Ám	30 Áin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
Amphenol ICC (FCI) 68604-115HLF	Through Hole	Black	Unshrouded	Push-Pull	UL94 V-0	Square	1	0.1 in	2.54 mm		15	0.6 in	15.24 mm	9.65 mm	0.38 in	0.12 in	3.05 mm	Header	Solder	0.76 Ám	30 Áin	Phosphor Bronze	All	Male Pin	3 A	125 °C	-65 ░C	0.1 in	2.54 mm	Gold or Gold GXT™
