PS00 Series
Manufacturer: TE Connectivity Corcom Filters
Beta
⌘K
PWR ENT MOD RCPT IEC320-C14 PNL
| Part | Mounting Type | Panel Cutout Dimensions | Current Rating - Filter | Termination | Termination | Termination | Approval Agency | Features | Panel Thickness [Min] | Panel Thickness [Max] | Panel Thickness [Min] | Panel Thickness [Max] | Accomodates a Fuse | Voltage Rating - Appliance Inlet | Connector Style | Fuse Holder, Drawer | Current Rating - Appliance Inlet | Connector Type | Filter Type | Operating Temperature [Max] | Operating Temperature [Min] | Termination Style | Configuration | Current | Applications | Voltage - Rated DC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 6 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip Shielded | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 6 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | ||||||||
 TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 6 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 6 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | ||||||||
 TE Connectivity Corcom Filters | Panel Mount | CSA UL VDE | Single Phase | 40 °C | -10 °C | Quick Connect | Single Stage | 3 A | General Purpose | 80 V | ||||||||||||||||
TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 3 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip Shielded Voltage Selector | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 3 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | ||||||||
TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 10 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip Shielded Voltage Selector | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 10 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | ||||||||
 TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 6 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip Shielded Voltage Selector | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 6 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | ||||||||
 TE Connectivity Corcom Filters | Panel Mount | CSA UL VDE | DC | 40 °C | -10 °C | Quick Connect | 6 A | General Purpose | 80 V | |||||||||||||||||
 TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 6 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Conversion Clip Voltage Selector | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Fuse Holder | 6 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial | ||||||||
TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 3 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | Shielded Voltage Selector | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Twin Fused | 3 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial Medical | ||||||||
 TE Connectivity Corcom Filters | Panel Mount Snap-In | Variable Size | 6 A | Quick Connect | 0.187 " | 4.7 mm | CSA UL VDE | 0.79 mm | 2.9 mm | 0.031 " | 0.114 in | 120 VAC | IEC 320-C14 | Twin Fused | 6 A | Receptacle Male Blades - Module | Filtered (EMI RFI) - Commercial |
