RAYCHEM HTAT Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
HEATSHRINK 0.158" X 4' BLACK
| Part | Inner Diameter - Supplied [diameter] | Inner Diameter - Supplied [diameter] | Inner Diameter - Recovered | Inner Diameter - Recovered | Type | Operating Temperature [Min] | Operating Temperature [Max] | Shrink Temperature | Features | Shrinkage Ratio | Shelf Life | Length [x] | Length [x] | Color | Material | Recovered Wall Thickness | Recovered Wall Thickness | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Max] | Storage/Refrigeration Temperature [Min] | Storage/Refrigeration Temperature [Max] | Length | Length | Length | Inner Diameter - Recovered [diameter] | Inner Diameter - Recovered [diameter] | Length [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 4.01 mm | 0.158 " | 0.039 in | 0.99 mm | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | 4 ft | 1.22 m | Black | Polyolefin (PO) Irradiated | 0.99 mm | 0.039 in | 0 °C | 35 °C | 32 °F | 95 °F | ||||||
 TE Connectivity AMP Connectors | 16 mm | 0.63 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | Black | Polyolefin (PO) Irradiated | 1.75 mm | 0.069 in | 0 °C | 35 °C | 32 °F | 95 °F | 40 mm | 1.57 " | 0.131 ' | 0.158 in | 4.01 mm | |||||
 TE Connectivity AMP Connectors | 16 mm | 0.63 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | Black | Polyolefin (PO) Irradiated | 1.75 mm | 0.069 in | 0 °C | 35 °C | 32 °F | 95 °F | 0.158 in | 4.01 mm | ||||||||
TE Connectivity AMP Connectors | 11.99 mm | 0.472 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | Black | Polyolefin (PO) Irradiated | 1.4 mm | 0.055 in | 0 °C | 35 °C | 32 °F | 95 °F | 1 m 75 m | 3.28 ft 246.1 ' | 0.118 in | 2.99 mm | ||||||
 TE Connectivity AMP Connectors | 24 mm | 0.945 " | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | Black | Polyolefin (PO) Irradiated | 2.24 mm | 0.088 in | 0 °C | 35 °C | 32 °F | 95 °F | 45 mm | 1.77 " | 0.147 ' | 0.236 in | 5.99 mm | |||||
TE Connectivity AMP Connectors | 3.99 mm | 0.157 " | 0.039 in | 0.99 mm | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | 0.114 ft | 35 mm | Black | Polyolefin (PO) Irradiated | 0.99 mm | 0.039 in | 0 °C | 35 °C | 32 °F | 95 °F | 1.37 " | |||||
TE Connectivity AMP Connectors | 11.99 mm | 0.472 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | 4 ft | 1.22 m | Black | Polyolefin (PO) Irradiated | 1.4 mm | 0.055 in | 0 °C | 35 °C | 32 °F | 95 °F | 0.118 in | 2.99 mm | ||||||
TE Connectivity AMP Connectors | 32 mm | 1.26 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | 4 ft | 1.22 m | Black | Polyolefin (PO) Irradiated | 2.49 mm | 0.098 in | 0 °C | 35 °C | 32 °F | 95 °F | 0.315 in | 8 mm | ||||||
TE Connectivity AMP Connectors | |||||||||||||||||||||||||||
TE Connectivity AMP Connectors | 48.01 mm | 1.89 in | Tubing Semi-Flexible | -55 C | 125 °C | 80 °C | Adhesive Lined Flame Retardant Fluid Resistant | 4 to 1 | 36 Months | Black | Polyolefin (PO) Irradiated | 2.54 mm | 0.1 in | 0 °C | 35 °C | 32 °F | 95 °F | 0.512 in | 13 mm |
