8105 Series

Catalog

MULTI-PAIR 10COND 24AWG

Part	Shield Material	Shield Coverage	Shield Type	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Jacket Color	Wire Gauge	Usage	Length	Length	Jacket (Insulation) Material	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Insulation	Number of Conductors	Ratings	Features	Operating Temperature [Max]	Operating Temperature [Min]	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Length [x]	Length [x]
Belden Inc. 8105 060500	Aluminum Copper Tinned	65 % 100 %	Braid Foil	0.035 in	0.889 mm	Multi-Pair	Chrome	24 AWG	Computer	152.4 m	500 ft	Poly-Vinyl Chloride (PVC)	Copper Tinned	7	32 AWG	Foam Polyethylene (FPE)	10	UL Style 2919	Drain Wire	80 °C	-30 ░C	7.7 mm	0.303 in
Belden Inc. 8105 0601000	Aluminum Copper Tinned	65 % 100 %	Braid Foil	0.035 in	0.889 mm	Multi-Pair	Chrome	24 AWG	Computer	304.8 m	1000 ft	Poly-Vinyl Chloride (PVC)	Copper Tinned	7	32 AWG	Foam Polyethylene (FPE)	10	UL Style 2919	Drain Wire	80 °C	-30 ░C	7.7 mm	0.303 in
Belden Inc. 8105 060100	Aluminum Copper Tinned	65 % 100 %	Braid Foil	0.035 in	0.889 mm	Multi-Pair	Chrome	24 AWG	Computer			Poly-Vinyl Chloride (PVC)	Copper Tinned	7	32 AWG	Foam Polyethylene (FPE)	10	UL Style 2919	Drain Wire	80 °C	-30 ░C	7.7 mm	0.303 in	100 ft	30.5 m
