77-1N Series

Catalog

SOFT-SHIELD 3500, FOF, 22X20MM

...

Part	Storage/Refrigeration Temperature	Storage/Refrigeration Temperature	Shelf Life Start	Shelf Life	Attachment Method	Material	Shape	Length	Length	Plating	Type	Width [x]	Width [x]	Operating Temperature [Max]	Operating Temperature [Min]	Height	Height	Height [z]	Height [z]	Width	Width	Width	Width [y]	Width [y]
Parker Chomerics 77-1N-3223-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam	0.866 in	22 mm	70 °C	-40 C	0.787 in	19.99 mm
Parker Chomerics 77-1N-3628-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	D-Shape	2.44 m	96 in	Nickel	Fabric Over Foam	0.079 "		70 °C	-40 C			10.01 mm	0.394 in	2.01 mm
Parker Chomerics 77-1N-3840-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Stealth	2.44 m	96 in	Nickel	Fabric Over Foam	0.1 in	2.54 mm	70 °C	-40 C	0.3 in	7.62 mm
Parker Chomerics 77-1N-3219-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam			70 °C	-40 C			5 mm	0.197 in	1.5 mm	0.059 in
Parker Chomerics 77-1N-3142-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam	1.575 in	40.01 mm	70 °C	-40 C			19.05 mm	0.75 in
Parker Chomerics 77-1N-3557-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam	0.134 in	3.4 mm	70 °C	-40 C		17.5 mm		0.689 in
Parker Chomerics 77-1N-3110-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam			70 °C	-40 C			5 mm	0.197 in	0.098 in		2.49 mm
Parker Chomerics 77-1N-3136-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam			70 °C	-40 C			8 mm	0.315 in				0.078 "	1.98 mm
Parker Chomerics 77-1N-3164-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam	0.079 "		70 °C	-40 C			11.99 mm	0.472 in	2.01 mm
Parker Chomerics 77-1N-3104-09600	70 °F	21 °C	Date of Shipment	24 Months	Adhesive	Nickel-Copper Taffeta over Urethane Foam - Halogen Free	Rectangle	2.44 m	96 in	Nickel	Fabric Over Foam			70 °C	-40 C	0.157 in	3.99 mm						0.078 "	1.98 mm
