CC-1-3061 Series

Catalog

PMI DIA .319" (8.10MM) WHITE 24V

Part	Voltage	Panel Cutout Shape	Lens Style	Termination Style	Lens Color	Panel Cutout Dimensions	Panel Cutout Dimensions	Ratings	Lens Size	Lens Size	Type	Current	Millicandela Rating	Viewing Angle	Lamp Color
Visual Communications Company - VCC CC-1-3061-9911-I	3.2 V 24 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm	DC	5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
Visual Communications Company - VCC CC-1-3061-9922-I	3.2 V 5 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm	DC	5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
Visual Communications Company - VCC CC-1-3061-9909-I	3.2 V 12 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm	DC	5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
Visual Communications Company - VCC CC-1-3061-0000-I	3.2 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm		5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
Visual Communications Company - VCC CC-1-3061-9913-I	3.2 V 48 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm	DC	5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
Visual Communications Company - VCC CC-1-3061-9915-I	3.2 V 60 V	Round	Round with Domed Top	Wire Leads - 6.000" (152.40mm)	White	0.32 "	8.1 mm	DC	5 mm	T-1 3/4	LED	20 mA	27000 mcd	15 °	White
