74HC30 Series

Catalog

IC GATE NAND 1CH 8-INP 14SSOP

Part	Package Width	Package Name	Package Length	Input Logic Level - High (Max)	Input Logic Level - High (Min)	Operating Temperature (Max)	Operating Temperature (Min)	Current - Output High	Current - Output Low	Input Logic Level - Low (Min)	Input Logic Level - Low (Max)	Mounting Type	Logic Type	Voltage - Supply (Minimum)	Voltage - Supply (Maximum)	Number of Inputs	Current - Quiescent (Max)	Number of Circuits	Max Propagation Delay	Max CL
NXP USA Inc. 74HC30DB,118	5.3 mm	14-SSOP	0.209 in	3.2 V	1.2 V	125 °C	-40 °C	5.2 mA	5.2 mA	0.5 V	1.8 V	Surface Mount	NAND Gate	2 V	6 V	8	2 µA	1	22 ns	50 pF
NXP USA Inc. 74HC30D/AUJ	3.9 mm	14-SO 14-SOIC	0.154 in	4.2 V	1.5 V	125 °C	-40 °C	5.2 mA	5.2 mA	0.5 V	1.8 V	Surface Mount	NAND Gate	2 V	6 V	8	2 µA	1	22 ns	50 pF
NXP USA Inc. 74HC30PW/S400118	4.4 mm	14-TSSOP	0.173 in	4.2 V	1.5 V	125 °C	-40 °C	5.2 mA	5.2 mA	0.5 V	1.8 V	Surface Mount	NAND Gate	2 V	6 V	8	2 µA	1	22 ns	50 pF
NXP USA Inc. 74HC30N,652	7.62 mm	14-DIP	0.3 in	4.2 V	1.5 V	125 °C	-40 °C	5.2 mA	5.2 mA	0.5 V	1.8 V	Through Hole	NAND Gate	2 V	6 V	8	2 µA	1	22 ns	50 pF
NXP USA Inc. 74HC30PW,112	4.4 mm	14-TSSOP	0.173 in	4.2 V	1.5 V	125 °C	-40 °C	5.2 mA	5.2 mA	0.5 V	1.8 V	Surface Mount	NAND Gate	2 V	6 V	8	2 µA	1	22 ns	50 pF
