SEAF-30 Series

Board to Board & Mezzanine Connectors .050" SEARAY High-Speed High-Density Open-Pin-Field Array Socket

Catalog

Board to Board & Mezzanine Connectors .050" SEARAY High-Speed High-Density Open-Pin-Field Array Socket

Part	Number of Rows	Number of Positions	Height Above Board	Height Above Board	Contact Finish Thickness	Contact Finish Thickness	Connector Type	Contact Finish	Features	Mated Stacking Heights	Pitch [x]	Pitch [x]	Mounting Type
Samtec Inc. SEAF-30-05.0-L-05-2-A-K-TR	5	150	5.05 mm	0.199 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide Pick and Place	7 mm 8 mm 8.5 mm 11.5 mm 12 mm 14 mm 16 mm 18 mm	0.05 in	1.27 mm	Surface Mount
Samtec Inc. SEAF-30-05.0-L-08-2-A-LP-K-TR	8	240	5.05 mm	0.199 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide Latches Pick and Place	7 mm 8 mm 8.5 mm 11.5 mm 12 mm 14 mm 16 mm 18 mm	0.05 in	1.27 mm	Surface Mount
Samtec Inc. SEAF-30-01-L-04-1-RA-TR		120	7.9 mm	0.311 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide		0.05 in	1.27 mm	Surface Mount Right Angle
Samtec Inc. SEAF-30-05.0-L-08-1-A-K-TR	8	240	5.05 mm	0.199 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide Pick and Place	7 mm 8 mm 8.5 mm 11.5 mm 12 mm 14 mm 16 mm 18 mm	0.05 in	1.27 mm	Surface Mount
Samtec Inc. SEAF-30-05.0-L-10-1-A-K-TR	10	300	5.05 mm	0.199 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide Pick and Place	7 mm 8 mm 8.5 mm 11.5 mm 12 mm 14 mm 16 mm 18 mm	0.05 in	1.27 mm	Surface Mount
Samtec Inc. SEAF-30-01-L-04-2-RA-GP-K-TR		120	7.9 mm	0.311 in	10 Áin	0.25 Ám	High Density Array Female	Gold	Board Guide Mating Flange Pick and Place		0.05 in	1.27 mm	Surface Mount Right Angle
Samtec Inc. SEAF-30-01-S-06-1-RA-GP-K-TR	6	180	10.45 mm	0.411 in	30 Áin	0.76 Ám	High Density Array Female	Gold	Board Guide Mating Flange Pick and Place		0.05 in	1.27 mm	Surface Mount Right Angle
Samtec Inc. SEAF-30-01-S-04-1-RA-K-TR		120	7.9 mm	0.311 in	30 Áin	0.76 Ám	High Density Array Female	Gold	Board Guide Pick and Place		0.05 in	1.27 mm	Surface Mount Right Angle
Samtec Inc. SEAF-30-01-S-06-1-RA-K-TR	6	180	10.45 mm	0.411 in	30 Áin	0.76 Ám	High Density Array Female	Gold	Board Guide Pick and Place		0.05 in	1.27 mm	Surface Mount Right Angle
Samtec Inc. SEAF-30-01-S-04-1-RA-GP-K-TR		120	7.9 mm	0.311 in	30 Áin	0.76 Ám	High Density Array Female	Gold	Board Guide Mating Flange Pick and Place		0.05 in	1.27 mm	Surface Mount Right Angle
