B07D03 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
B07D034BA2-0125 = M5757/23-015
| Part | Coil Resistance | Seal Rating | Must Release Voltage | Operate Time | Coil Type | Contact Form | Operating Temperature [Min] | Operating Temperature [Max] | Must Operate Voltage | Coil Current | Contact Rating (Current) | Mounting Type | Release Time | Termination Style | Relay Type | Contact Material | Coil Voltage | Grade |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 19 Ohms | Sealed - Hermetically | 0.4 VDC | 10 ms | Non Latching | DPDT (2 Form C) | -65 ░C | 125 °C | 3.3 VDC | 315.8 mA | 10 A | Through Hole | 10 ms | PC Pin | General Purpose | Silver Cadmium Oxide (AgCdO) | ||
 TE Connectivity AMP Connectors | 300 Ohms | Sealed - Hermetically | 2.3 VDC | 15 ms | Non Latching | DPDT (2 Form C) | -65 ░C | 125 °C | 13 VDC | 88.3 mA | 10 A | Through Hole | 15 ms | PC Pin | General Purpose | Silver Cadmium Oxide (AgCdO) | 26.5 VDC | Military |
 TE Connectivity AMP Connectors | 75 Ohms | Sealed - Hermetically | 0.8 VDC | 15 ms | Non Latching | DPDT (2 Form C) | -65 ░C | 125 °C | 6.5 VDC | 160 mA | 10 A | Through Hole | 15 ms | PC Pin | General Purpose | Silver Cadmium Oxide (AgCdO) | 12 VDC | Military |
