QME48T40033 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
DC DC CONVERTER 3.3V 132W
| Part | Applications | Control Features | Voltage - Isolation | Voltage - Input (Max) [Max] | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Type | Efficiency | Power (Watts) | Package / Case | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Current - Output (Max) [Max] | Voltage - Output 1 | Voltage - Input (Min) [Min] | Type | Number of Outputs | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | ITE (Commercial) | Active Low Enable | 2000 V | 75 V | 85 °C | -40 C | Through Hole | 91 % | 132 W | 8-DIP Module 1/4 Brick | 36.8 mm | 58.4 mm | 10.8 mm | 0.43 in | 1.45 in | 2.3 in | 40 A | 3.3 V | 36 V | Isolated Module | 1 | OCP OTP OVP Remote On/Off UVLO |
 Bel Fuse Inc. | ITE (Commercial) | Active High Enable | 2000 V | 75 V | 85 °C | -40 C | Through Hole | 91 % | 132 W | 8-DIP Module 1/4 Brick | 36.8 mm | 58.4 mm | 10.8 mm | 0.43 in | 1.45 in | 2.3 in | 40 A | 3.3 V | 36 V | Isolated Module | 1 | OCP OTP OVP Remote On/Off SCP UVLO |
Bel Fuse Inc. | ITE (Commercial) | Active Low Enable | 2000 V | 75 V | 85 °C | -40 C | Through Hole | 91 % | 132 W | 8-DIP Module 1/4 Brick | 36.8 mm | 58.4 mm | 10.8 mm | 0.43 in | 1.45 in | 2.3 in | 40 A | 3.3 V | 36 V | Isolated Module | 1 | OCP OTP OVP Remote On/Off SCP UVLO |
Bel Fuse Inc. | ITE (Commercial) | Active Low Enable | 2000 V | 75 V | 85 °C | -40 C | Through Hole | 91 % | 132 W | 8-DIP Module 1/4 Brick | 36.8 mm | 58.4 mm | 10.8 mm | 0.43 in | 1.45 in | 2.3 in | 40 A | 3.3 V | 36 V | Isolated Module | 1 | OCP OTP OVP Remote On/Off SCP UVLO |
