630-8W8 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB RCPT 8POS R/A SLDR
| Part | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Voltage Rating | Contact Material | Color | Connector Type | Mounting Type | Contact Finish | Termination | Number of Rows | Contact Type | Current Rating (Amps) | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [x] | Shell Size, Connector Layout | Flange Feature | Flange Feature | Connector Style | Backset Spacing | Backset Spacing | Material Flammability Rating | Number of Positions | Shell Material, Finish | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 10 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | Housing/Shell | 4-40 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 20 A | 4 | 8W8 C DC | Board Side (M3) | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Nickel Plated Steel | Flash | ||||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Coax | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | Housing/Shell (Unthreaded) | Combo D-Sub | 0.37 in | 9.4 mm | UL94 V-0 | 8 | Nickel Plated Steel | Shielded | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 20 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | Housing/Shell | 4-40 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Board Lock Mounting Brackets | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Coax | 4 | 8W8 C DC | M3 | Combo D-Sub | 0.37 in | 9.4 mm | UL94 V-0 | 8 | Nickel Plated Steel | Flash | Board Lock Mounting Brackets | ||||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 10 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | 4-40 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Nickel Plated Steel | Board Lock | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 10 A | 4 | 8W8 C DC | M3 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Nickel Plated Steel | Flash | Board Lock Mounting Brackets | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 20 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | Housing/Shell | 4-40 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | |||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 40 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | 4-40 | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Nickel Plated Steel | Board Lock Mounting Brackets | ||
 EDAC Inc. | Polyester Thermoplastic | -55 C | 125 °C | 125 VDC | Copper Alloy | Black | Receptacle Female Sockets | Right Angle Through Hole | Gold | Solder | 1 | Power | 40 A | 30 Áin | 0.76 Ám | 4 | 8W8 C DC | Housing/Shell (M3) | Combo D-Sub | 0.52 " | 13.2 mm | UL94 V-0 | 8 | Board Lock Mounting Brackets |
