10025026 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN PCI EXP FMALE 164POS 0.039
| Part | Material - Insulation | Mounting Type | Pitch | Pitch | Termination | Number of Positions | Color | Card Type | Gender | Card Thickness | Card Thickness | Read Out | Features | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish Thickness | Contact Finish Thickness | Contact Finish | Number of Rows [custom] | Flange Feature | Flange Feature | Flange Feature | Contact Type | Contact Material | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | 30 Áin | 0.76 Ám | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | |
 Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 98 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash | ||
 Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | 15 µin | 0.38 µm | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | |
 Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 64 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash | ||
Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash | ||
Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 36 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash | ||
 Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | 30 Áin | 0.76 Ám | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | |
Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | 30 Áin | 0.76 Ám | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | |
Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash | ||
Amphenol ICC (FCI) | Glass Filled Nylon Polyamide (PA) | Board Edge Straddle Mount | 1 mm | 0.039 in | Solder | 164 | Black | PCI Express™ | Female | 1.57 mm | 0.062 in | Dual | Card Extender Locking Ramp | -55 C | 85 °C | Gold | 2 | Straddle Mount Opening Unthreaded | 2 mm | 0.079 " | Cantilever | Copper Alloy | Flash |
