861400242 Series

Catalog

CONN HEADER R/A 24POS 2.54MM

Part	Voltage Rating	Pitch - Mating	Pitch - Mating	Material Flammability Rating	Contact Finish - Post	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Connector Type	Number of Positions	Fastening Type	Insulation Material	Contact Material	Termination	Number of Positions Loaded	Number of Rows	Contact Shape	Shrouding	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Length - Mating [x]	Contact Length - Mating [x]	Contact Length - Post	Contact Length - Post	Current Rating (Amps)	Contact Type
Amphenol ICC (FCI) 861400242LO1332LF	500 V	0.1 in	2.54 mm	UL94 V-0	Tin	100 °C	-40 °C	Through Hole Right Angle	Breakaway Header	24	Push-Pull	Thermoplastic	Copper Alloy	Solder	All	2	Square	Unshrouded	2.54 mm	0.1 in	0.224 in	5.7 mm	2.5 mm	0.098 in	3 A	Male Pin
Amphenol ICC (FCI) 861400242LO1332	500 V	0.1 in	2.54 mm	UL94 V-0		100 °C	-40 °C	Through Hole Right Angle	Breakaway Header	24	Push-Pull	Thermoplastic	Copper Alloy	Solder	All	2	Square	Unshrouded	2.54 mm	0.1 in	0.224 in	5.7 mm	2.5 mm	0.098 in	3 A	Male Pin
